Amptech Solar Transformers

Solar Transformers are working with Step down voltage and Step up voltage with the same frequency. Solar transformers operate with fluctuating voltage and current depending on available sunlight conditions.

Amptech Solar transformers are specially designed to withstand heavy short circuit current and Impulse voltage and manufacture up to 2500 KVA and 33 KV Insulation level

Technical Specifications

KVA Up to 1000 KVA
Primary Voltage(HV) : 11 KV, 22 KV, 33 KV
Secondary Voltage(LV) : Upto 1000 V
Frequency : 50 Hz
Phase : Three
Vector Group : DYN 11
Loses : As per IS Standard
Temperature : 50°, 55°

Accessories

Features

Linear Tap Switch
Pressure Relief Valve
Magnetic type oil level indicator
Cover mounted core-coil assembly
Marshelling box with mercury control switch for temperature
Digital meter provided for measuring temperature

Call us to get the best quote

Advantages

Design

Manufacturing of Energy Efficient Transformers as per IS-1180 Part 1-2014 quality standards. We do various levels of rigorous testing to ensure trouble-free working. Designed to reduce losses and operate various sunlight conditions

Operation

Amptech Solar transformers are rated according to the size of solar generation capacity and collection array voltage class, meeting all applicable standards

Outcome

100% cost saving and ensure a short pay-back time on the investment
